ACTIVITY: Modeling Plate Movement

NGSS Science and Engineering Practices
Analyzing and Interpreting Data
Developing and Using Models

Students create and test models of tectonic plate movement and use them to analyze and interpret features on a map of Earth.

NGSS Crosscutting Concepts
Patterns
Stability and Change

By interacting with the models, students observe that although continental features appear stable, Earth's features are created by changes in plate movement.

NGSS Disciplinary Core Ideas
ESS2.B: Plate Tectonics and Large-Scale System Interactions

Students extrapolate from small-scale models of plate movement to large-scale geologic events in order to better understand the dynamics of Earth's features.

Table of Contents
Activity: Modeling Plate Movement
The activity below draws from the content in the page Exploring Plate Tectonics.

Phenomenon:

Volcanic eruptions are common in Hawaiʻi (Fig. 1)!

Fig. 1. Lava flows on the island of Hawai'i.
Image courtesy of GIPHY

Inquiry:

  • Where does lava come from?
  • Why do volcanic eruptions happen mostly on Hawai'i island?
  • How did the Hawaiian Islands form?

Guiding Questions:

  1. What is the evidence that the land on earth is moving?
  2. Where did the lava that formed the Hawaiian Island chain come from?

Activity:

Discover how geologic features form by modeling the slow movement of Earth's tectonic plates.

Note: This activity has Further Investigations below (an interactive game, crossword puzzle, and plate labeling sheets) to help solidify understanding of vocabulary.

Materials:

Part A. Model:

  • Deck of cards, or tangrams
  • Shaving cream
  • Small pebbles
  • Spatula or wooden spoon
  • Towels for clean up
  • Baking pan, tub, or wide bucket
  • Mesh mat or screen
  • Student Worksheet and Teacher Guide (attachment below)
    ACTIVITY SHEET

    Student Worksheet: Plate Tectonics

    TEACHER GUIDE

    Teacher Guide: Plate Tectonics

    This teacher guide follows the procedure written here and in the student worksheet with additional instructions and guidelines. We highly recommend starting this activity by introducing the Phenomenon, Inquiry, and Guiding Questions from the top of this webpage.
Recommendations:
  • This activity can be done using edible ingredients (like graham crackers or cookies for plates and cool whip or pudding for magma).
  • For the mesh or screen, a roll of 'no slip' shelf liner works well.

Part B. Map:

  • Map of Earth's plates overlay (attachment below printed on clear acetate)
    ACTIVITY SHEET

    Earth's Plates Overlay

    Summary Not available-no caption
  • Extra sheet of clear acetate
  • Dry erase markers
  • World map showing seafloor features (attachment below)
    (Note: this is more effective when printed in color)
    ACTIVITY SHEET

    World Map

Recommendations:

There are two ways to do the map activity:

  1. Print the map of Earth's plates on clear acetate so that it can be placed over the world map, or
  2. Print the map on plain paper and cut out each of the plates. Students can then try to connect the plates back together on top of the world map with seafloor features. (Note: You may also laminate the map of Earthʻs plates before cutting and then use the plates instead of cards or tangrams in the model portion of the activity.)

Procedure:



<p>Fig. 2. An example of plate movement model. What will happen to the shaving cream layer when the cards move apart? What about when they move together?</p>

Fig. 2. An example of plate movement model. What will happen to the shaving cream layer when the cards move apart? What about when they move together?

Image by Kanesa Duncan-Seraphin

Part A. Prepare and Explore Your Model

  1. Follow your worksheet to set up and conduct your trials.
  2. Squirt a layer of shaving cream into the bottom of the pan or tub (Fig. 2).
  3. Use your spoon to flatten the shaving cream so it's evenly distributed.
  4. Gently place two of your plates on top of a pile of magma (shaving cream) so that they form a rectangle.
  5. Conduct your trials.

Trial #1: Divergence

  1. ​Before testing the plate movements, describe what you think will happen when you pull the plates apart.
  2. Very slowly, push down and gently slide the two plates apart.
  3. Record what happened on your worksheet.

Trial #2: Convergence

  1. ​Clean your plates and place them back on top to form a rectangle.
  2. Describe what you think will happen when you push one plate under the other.
  3. This time, push one plate down and under the other plate.
  4. Record what happened on your worksheet.

Trial #3: Transform Fault Movement

  1. ​Clean your plates and place them back on top to form a rectangle, this time leave a small space between the plates.
  2. Push down on the plates so a bit of magma comes up between.
  3. Put a few small pebbles on the magma in between the plates.
  4. Describe what you think will happen when you slide the plates in opposite directions along side each other.
  5. Gently slide the plates in opposite directions along side each other.
  6. Record what happened on your worksheet.

Trial #4: Island Chain Formation



<p>Fig. 3. Model demonstrating hot spot formation. What will happen when the shaving cream squirts up through the mat?</p>

Fig. 3. Model demonstrating hot spot formation. What will happen when the shaving cream squirts up through the mat?

Image by Sebastian Stewart

  1. Set aside the model of convergent and divergent plates to prepare a new model for island chain formation.
  2. Using the mesh material (remember, this also represents one of Earth's plates), hold it flat and free from any surface.
  3. With help from another partner, hold the can under the plate and point it upwards (Fig. 3).
  4. Describe what you think will happen when magma (shaving cream) squirts upwards through the plate (mesh material).
  5. Gently squirt a small amount of magma three times (stay still as you squirt the can!) and slowly move the plate after each squirt.
  6. Record what happened on your worksheet.
  7. Challenge: see if you can recreate the Hawaiian Island Chain!



<p>Fig. 4. The Hawaiian Island chain. Can you recreate this in your model?</p>

Fig. 4. The Hawaiian Island chain. Can you recreate this in your model?

Image courtesy of Wikimedia Commons

Part B. Compare your model to a map of Earth's features

  1. Using what you've learned in this experiment, take out the world map, clear acetate sheet, and map of Earth's plates overlay (printed on clear acetate).
  2. Look at the world map and see if you can identify any plate boundaries where convergence, divergence, or transform movement may occur. (hint: start by looking in the middle of the Atlantic Ocean)
  3. Place the clear acetate sheet on top of the map.
  4. As best as you can, trace the plate boundary in the middle of the Atlantic ocean.
  5. Continue tracing areas that you think are potential plate boundaries.
  6. Place the map of Earth's plates overlay in between your trace layer and the map to compare what you've traced with the official plate boundaries.
  7. Continue tracing plates, using the map and plate overlay as a guide.
  8. Record your observations on your worksheet.

Activity Questions:

  1. Name one thing you have learned about Earth's features from this activity.
  2. Where do earthquakes generally occur?
  3. Are the Hawaiian Islands on a plate boundary?
  4. Why does Hawai'i have more volcanic activity than some other locations on Earth?
  5. What is a hot spot?
  6. How did the Hawaiian Islands form?

Further Investigations:

  1. Crossword Puzzle!

Click on the attachments below to complete the plate tectonics crossword puzzle!



ACTIVITY SHEET

Plate Tectonics Crossword Puzzle



TEACHER GUIDE

Plate Tectonics Crossword Puzzle - Answers


  1. Plate Labeling!

Practice your vocabulary by labeling the parts of the different plates.



ACTIVITY SHEET

Plate Movement Labeling Sheets



TEACHER GUIDE

Plate Movement Labeling Sheets - Answers
