Activity: Corals

NGSS Science and Engineering Practices:

NGSS Crosscutting Concepts:

NGSS Disciplinary Core Ideas:

Materials

  • Table 3.3
  • Fig. 3.31
  • Fig. 3.32
  • Fig. 3.33
  • Fig. 3.34
  • Reef-building coral skeletons (five or more of different species)
  • Dissecting microscope or hand lens
  • Calipers or ruler
  • Coral identification key (optional)

<p><strong>Fig. 3.31.</strong> Examples of solitary coral calyces (<strong>A</strong>) <em>Tubastraea</em> tube coral with side walls (<strong>B</strong>) <em>Fungia</em> mushroom coral without side walls</p><br /> <p><strong>Fig. 3.32.</strong> Arrangement of calyces (cups) in some colonial corals</p><br />

<p><strong>Fig. 3.33.</strong> Arrangement of septa in some colonial corals</p><br /> <p><strong>Fig. 3.34.</strong> Septa variations in colonial corals (shown with part of side walls removed)</p><br />

Procedure

  1. Closely examine each coral skeleton
    1. Place each coral skeleton specimen on the stage of the dissecting microscope
    2. Adjust the lighting to maximize contrast and shadows to best view fine skeleton details

  2. Describe the features of the coral cuplike structures, known as calyces in Table 3.3. Refer to Figs. 3.31, 3.32, 3.33, and 3.34 as needed.
    1. Use the ruler to measure the cup, or calyx, diameter and record it in Table 3.3.
    2. Use the dissecting microscope or hand lens to closely examine the calyx features.
    3. Count the number of divisions, known as septa, per calyx and the features of the septa walls.
    4. Record the coral colony shape in Table 3.3. “Massive” coral colonies take solid, stone-like forms while “branching” colonies appear bush-like.

  3. Sketch the coral colony
    1. without magnification in Table 3.3. Indicate the appropriate scale in your sketch by using a ruler.
    2. under magnification from the dissection scope or hand lens in Table 3.3. Indicate the appropriate scale in your sketch by using a ruler.

  4. Repeat steps 1 through 3 for each coral specimen.

  5. (Optional) Use a dichotomous key to identify the coral skeletons.



Activity Questions:
  1. Define the following terms:
    1. polyp
    2. colonial coral
    3. elevated cup
    4. septa

  2. How do the calyx features of the colonial coral specimens differ? How are the specimens similar?

  3. How are the individual calyces in a coral colony made? How does a colonial coral seem to grow? Explain by making sketches.

  4. Which coral calyx features are missing in a solitary coral like Fungia? See Fig. 3.31 B.

  5. Some coral polyps are as small as the lower-case letter o in this text (approximately three millimeters in diameter). How can these tiny animals build massive coral heads and entire coral reefs?

  6. Some coral species have sprawling branches while others adopt more solid, massive shapes.
    1. What are the advantages and disadvantages of these two coral forms? Recall that corals acquire energy both from photosynthesis and from capturing plankton.
    2. For what habitat would a massive-form coral species be well adapted?
    3. For what habitat would a branching-form coral species be well adapted?

  7. Storm disturbance on reef-building corals
    1. Which of the species you observed would probably break during a hurricane or heavy storm?
    2. What skeletal features make one coral more fragile than another?
